Land Pride CP3030

Double tap to zoom

Features	Benefits
Removable carbide picks	Uses rocket fin technology that is built into the picks for longer life. Easy to replace.
Skid shoes adjust independently with hydraulic cylinders	Allows the planer to follow curb and gutter as well as the contour of the road or street.
Tilt, depth, and sideshift adjust hydraulically	All functions are integrated into the multi-function grips of the SSV/SVL.
Case drain	Protects hydraulic motor and seals.

Model Number	CP3030
Cutting Width inches/cm	30/76
Cutting Depth inches/cm	0 to 6/ 0 to 15
Number of Picks	60
Min. hydraulic flow gpm/Lpm	30/114
Max. hydraulic flow gpm/Lpm	42/159
Minimum pressure psi/MPa	2500/17.2
Maximum pressure psi/MPa	5000/34.4
Tilt capability degrees	10
Sideshift travel inches/cm	26/66
Wall clearance inches/cm	4/10
Planetary gearbox oil type	EP90 or SAE75W90 Synthetic Gear lubricant
Planetary gearbox oil capacity	Approximately 30 oz/1L
Approximate weight lbs/kg	1991/903
